The Lynx Power In is a 2 pole modular DC busbar, used to connect batteries to the Lynx DC distribution system.

Lynx Power In, contains 1000A positive and negative busbars with 4 connections for batteries, loads or chargers and a ground connection.

Please note the M8 Model is discontinued.

Features:

- Voltage range 9 - 60Vdc
- Current rating 1000A
- Busbar M10
- Enclosure material ABS
- Enclosure dimensions (hxwxd) 290 x 170 x 80mm
- Unit weight 2.1 kg
- Busbar material Tinned copper
- Busbar dimensions (hxw) 10 x 30mm
- Operating temperature range -40°C to +60°
- Storage temperature range -40°C to +60°
- Protection class IP22

Manual

Click here for Manual

Warranty

Click Here To View The Victron Energy Limited Warranty Policy DOCUMENT
